  2. IPSI505MW-40-220
IPSI505MW-40-220 image



  • Power sensitive electronics without interference
  • Can be used in wet or dusty environment
  • Rugged & reliable to ensure years of safe and trouble free operation
  • IP66 Watertight
  • Pure Sine Wave – 120 or 220 VAC / 50 or 60 Hz
  • Optional transfer relay for Off-Line UPS capability
  • Overload Protected
  • Ultra-quiet low EMI operation
  • Extra heavy input filtering to eliminate interference with other equipment sharing the same batteries
  • Crystal controlled for precise frequency (±0.01 Hz)
  • State-of-the art MosFet technology for reliable operation
  • Transformer type output to protect computers and other sensitive equipment from surges and spikes
  • Low voltage warning and shutdown circuitry to protect the batteries
  • Short circuit & Over-temperature protection
  • Over voltage and over temperature warning and shutdown circuitry to protect the inverter
  • Inrush protection to prevent excess current draw during DC connection
  • Thermostatically controlled fans
  • Built to the ISO9001:2015 Certified Quality Systems
  • Isolated input for positive or negative ground operation
  • Diagnostic LEDs and Audible Alarms
  • Two year warranty (parts and labor)Inverter Wizard’ software, the user can select output frequency, output voltage, and low voltage shutdown parameters from any Windows laptop through the standard micro-usb interface as well as monitoring and logging input and output voltages, output power and inverter temperature.


    Safety features include current limiting, short circuit protection, overtemperature warning and shutdown and low input voltage warning and shutdown (user adjustable).

    An Off-Line UPS options allows external AC to be routed through the inverter to the load. The inverter will take over supplying the load only if the external AC fails.
