	*FANUC Robot M-10iD*		*/16S*	*M-10iD/12*	*/10L*	*/8L*
M-10iD Brochure (English \| Chinese) ARC Mate 100iD Brochure (English \| Chinese)	*FANUC Robot ARC Mate 100iD*		*/16S*	*ARC Mate 100iD*	*/10L*	*/8L*
	Controlled axes		6
	Max. payload at wrist		16kg	12kg	10kg	8kg
	Motion range (X, Y)		1103mm, 1977mm	1441mm, 2616mm	1636mm, 3006mm	2032mm, 3762mm
	Repeatability		±0.02mm		±0.03mm
	Mass (without stand)		145kg		150kg	180kg
	Installation		Floor, Upside-down, Angle * Floor, Upside-down for 4 brake type
	Matching controller / Input power source capacity		R-30iB Plus (A-, B-cabinet), R-30iB Mate Plus (standard) / 2kVA
	Application	Handling	x
		Assembling	x
		Arc welding	x
		Sealing	x
		Others	Mold handling, Deburring

FANUC Robot ARC Mate 100iC / FANUC Robot M-10iA specification
	*FANUC Robot M-10iA*		*/12S*	*/12*	*/7L*	*/8L*	*/10MS*	*/10M*
M-10iA Brochure (English \| Chinese) M-10iA/8L Brochure (English) ARC Mate 100iC Brochure (English \| Chinese) ARC Mate 100iC/8L Brochure (English)	*FANUC Robot ARC Mate 100iC*		*/12S*	*/12*	*/7L*	*/8L*	–	–
	Controlled axes		6
	Max. payload at wrist		12kg		7kg	8kg	10kg
	Motion range (X, Y)		1098mm, 1872mm	1420mm, 2504mm	1632mm, 2930mm	2028mm, 3709mm	1101mm, 1878mm	1422mm, 2508mm
	Repeatability		±0.03mm			±0.035mm	±0.03mm
	Mass		130kg		135kg	150kg	130kg
	Installation		Floor, Upside-down, Angle
	Matching controller / Input power source capacity		R-30iB/R-30iB Plus (A-, B-cabinet), R-30iB Mate/R-30iB Mate Plus (standard) / 2kVA
	Application	Handling	x	x	x	x	x	x
		Assembling	x	x	x	x	x	x
		Arc welding	x	x	x	x	x	x
		Sealing	x	x	x	x	x	x
		Others	Mold handling, Deburring

FANUC Robot ARC Mate 120iD / FANUC Robot M-20iD specification
	*FANUC Robot M-20iD*		*M-20iD/25*	*/35*	*/12L*
M-20iD Brochure (English \| Chinese) ARC Mate 120iD Brochure (English \| Chinese)	*FANUC Robot ARC Mate 120iD*		*ARC Mate 120iD*	*/35*	*/12L*
	Controlled axes		6
	Max. payload at wrist		25kg	35kg	12kg
	Motion range (X, Y)		1831mm, 3461mm		2272mm, 4343mm
	Repeatability		±0.02mm	±0.03mm
	Mass (without stand)		250kg
	Installation		Floor, Upside-down, Angle
	Matching controller / Input power source capacity		R-30iB Plus (A-, B-cabinet), R-30iB Mate Plus (standard) / 3kVA
	Application	Handling	x
		Assembling	x
		Arc welding	x
		Sealing	x
		Others	Mold handling, Deburring

FANUC Robot M-20iA / FANUC Robot ARC Mate 120iC specification
	*FANUC Robot M-20iA*		*M-20iA*	*/12L*	*/20M*	*/35M*
M-20iA Brochure (English \| Chinese) ARC Mate 120iC Brochure (English \| Chinese)	*FANUC Robot ARC Mate 120iC*		*ARC Mate 120iC*	*/12L*	–	–
	Controlled axes		6
	Max. payload at wrist		20kg	12kg	20kg	35kg
	Motion range (X, Y)		1811mm, 3275mm	2009mm, 3672mm	1813mm, 3278mm
	Repeatability		±0.03mm
	Mass		250kg			252kg
	Installation		Floor, Upside-down, Angle
	Matching controller / Input power source capacity		R-30iB/R-30iB Plus (A-, B-cabinet), R-30iB Mate/R-30iB Mate Plus (standard) / 3kVA
	Application	Handling	x	x	x	x
		Assembling	x	x	x	x
		Arc welding	x	x	x	x
		Sealing	x	x	x	x
		Others	Mold handling, Deburring

FANUC Robot M-20iB specification
Brochure (English \| Chinese)	FANUC Robot M-20iB		/25	/25C	/35S
	Controlled axes		6
	Max. payload at wrist		25kg		35kg
	Motion range (X, Y)		1853mm, 3345mm		1445mm, 2591mm
	Repeatability		±0.02mm
	Mass		210kg		205kg
	Installation		Floor, Upside-down, Angle
	Matching controller / Input power source capacity		R-30iB/R-30iB Plus (A-, B-cabinet), R-30iB Mate/R-30iB Mate Plus (standard) / 3kVA		R-30iB Plus (A-, B-cabinet), R-30iB Mate Plus (standard) / 3kVA
	Application	Handling	x	x	x
		Assembling	x	x	x
		Arc welding	x	–	x
		Sealing	x	–	x
		Clean room	–	x	–
		Others	Mold handling, Deburring	–	Mold handling, Deburring

FANUC Robot M-710iC specification
Brochure (English \| Chinese)	FANUC Robot M-710iC		/45M	/50	/70	/12L	/20L	/20M	/50S	/50H
	Controlled axes		6							5
	Max. payload at wrist		45kg	50kg	70kg	12kg	20kg	20kg	50kg	50kg
	Motion range (X, Y)		2606 mm, 4575 mm	2050mm, 3545mm		3123 mm, 5609 mm	3110 mm, 558 3mm	2582 mm, 4609 mm	1359 mm, 2043 mm	2003mm, 3451mm
	Repeatability		±0.06 mm	±0.03 mm	±0.04 mm	±0.06mm			±0.03mm
	Mass		570kg	560kg		540kg		530kg	545kg	540kg
	Installation		Floor, Upside-down, Angle							Floor, Upside-down
	Matching controller / Input power source capacity		R-30iB/R-30iB Plus (A-, B-cabinet), R-30iB Mate/R-30iB Mate Plus (standard) / 12kVA							R-30iB/R-30iB Plus (A-, B-cabinet) / 12kVA
	Application	Handling	x	x	x	x	x	x	x	x
		Assembling	x	x	x	x	x	x	x	–
		Arc welding	x	x	x	x	x	x	x	–
		Sealing	x	x	x	x	x	x	x	–
		Spot welding	x	x	x	–	–	–	x	–
		Others	Mold handling, Deburring, Laser cutting							–

FANUC Robot R-1000iA specification
Brochure (English \| Chinese)	*FANUC Robot R-1000iA*		*/80F*	*/100F*	*/130F*	*/120F-7B*	*/80H*
	Controlled axes		6			7	5
	Max. payload at wrist		80kg	100kg	130kg	120kg	80kg
	Motion range (X, Y)		2230mm, 3738mm			2230mm, 3779mm	2230mm, 3465mm
	Repeatability		±0.03mm
	Mass		620kg	665kg	675kg	790kg	610kg
	Installation		Floor, Upside-down
	Matching controller		R-30iB/R-30iB Plus (A-, B-cabinet), R-30iB Mate/R-30iB Mate Plus (standard)		R-30iB/R-30iB Plus (A-, B-cabinet)
	Input power source capacity		12kVA		15kVA		12kVA
	Application	Handling	x	x	x	x	x
		Assembling	x	x	x	x	–
		Sealing	x	x	x	x	–
		Spot welding	x	x	x	x	–
